### Core Application Areas
1. **High-Temperature and High-Pressure Processes**
Petroleum refining processes typically involve extreme conditions of high temperature (up to 500°C) and high pressure (up to 10 MPa). Semi-welded plate heat exchangers can effectively cope with these harsh environments and are widely used for crude oil heating, lubricating oil cooling, and temperature control in high-temperature reactors.
2. **Waste Heat Recovery and Energy Saving & Emission Reduction**
In petrochemical production, a large amount of waste heat is emitted. Semi-welded plate heat exchangers can efficiently recover this waste heat (such as cracked gas, evaporator steam, etc.) for heating or preheating other process fluids, thereby significantly reducing energy consumption and production costs.
3. **Special Fluid Handling**
For fluids with highly corrosive or special chemical properties (such as ammonia refrigerant, brine, caustic soda solution, etc.), semi-welded plate heat exchangers, through laser welding technology, offer higher design pressure and better sealing performance than fully welded heat exchangers.
### Technical Advantages and Features
* **Rugged Structure:**
Laser welding tightly bonds two plates together, forming a cartridge structure that can withstand higher pressures than traditional gasketed heat exchangers (up to 65 bar on the welded side).
* **Leak-Proof:**
The tight seal on the welded side significantly reduces the risk of leakage under high pressure compared to traditional gasketed systems, ensuring compliance with the high safety and environmental requirements of the petroleum industry.
* **High Heat Exchange Efficiency:**
By eliminating the thickness loss of the gasket, semi-welded plate heat exchangers reduce heat transfer resistance and improve overall heat transfer efficiency.
* **High Adaptability:**
Capable of handling both high-temperature, high-pressure media and highly corrosive fluids, it represents a compromise design that can replace some shell-and-tube and fully welded heat exchangers.
### Typical Cases
* **Cracked Gas Recovery:**
In petroleum cracking units, waste heat from cracked gas at temperatures up to 1350℃ is recovered, significantly reducing energy consumption.
* **Hydrocracking:**
In hydrocracking units, waste heat is used for preheating reaction feed and cooling reaction products, achieving waste heat utilization and reducing the load on the heating furnace.
**Summary:** Semi-welded plate heat exchangers are a highly efficient, energy-saving, and reliable heat exchange solution for the petroleum industry, particularly suitable for critical process stages requiring the handling of high-pressure, corrosive fluids.
